ER70S-6 welding wire is a commonly used gas shielded welding wire.
Its raw materials usually include high-quality carbon steel wire rods, mainly composed of elements such as carbon, manganese, silicon, etc., to ensure that the welding wire has good welding performance.
Specifications:
| ire Size(mm) | φ 0.8 | φ 1.0 | φ 1.2 | φ 1.6 |
| Welding current(A) | 40~140 | 50~220 | 80~350 | 120~550 |
| Please be noted | Wire shall be stocked in dry. open the packs just when welding to avoid the wire rust. | |||
| Before welding please clean out the oil, rust, water etc from the work parts | ||||
| Chemical Composition(%) | |||||
| C | Mn | Si | S | P | Cu |
| 0.06-0.15 | 1.4-1.85 | 0.85-1.15 | ≤0.035 | ≤0.025 | ≤0.5 |
| Typical Mechanical Performance of Deposited Metal | ||||
| Test Item | Rm(MPa) | Rp0.2(MPa) | A(%) | Akv(J)/29℃ |
| Guaranteed | ≥500 | ≥420 | ≥22 | ≥27 |
The production process roughly includes the following steps:
1. Wire rod drawing: The raw material wire rod is drawn through a series of molds, gradually reducing the diameter to achieve the desired wire size.
2. Surface treatment: Remove impurities such as oxide scale and oil stains from the surface of the welding wire to improve welding quality.
3. Copper plating: Plating a layer of copper on the surface of the welding wire to increase conductivity and rust resistance.
ER70S-6 welding wire has a wide range of applications:
1. Mechanical manufacturing: used for welding various mechanical structures, such as frames, crane arms, etc.
2. Automotive industry: Welding of automotive components such as frames and bodies.
3. Construction industry: Welding of steel structures, such as steel structures for bridges and high-rise buildings.
4. Shipbuilding: Structural welding of ships.
5. Pressure vessel manufacturing: used to manufacture containers that can withstand a certain amount of pressure.
