6013 welding electrode is a common welding material.
| Chemical composition of welding metal (%) | ||||
| C | Mn | Si | S | P |
| ≦0.12 | 0.3-0.6 | ≦0.35 | ≦0.035 | ≦0.040 |
| Mechanical properties of welding metal | ||||
| Test Item | Tensile strength
Mpa |
Yield Strength
Mpa |
Elongation
% |
Impact Value
(J)0℃ |
| Guaranteed | ≥420mpa | ≥330mpa | ≥22 % | ≥47 |
In terms of specifications and models, it usually has multiple diameter specifications to choose from, commonly including 2.5mm, 3.2mm, 4.0mm, etc. Different diameters are suitable for weldments of different thicknesses.
Thickness
| Length | Packing | |
| 2.5mm | 300mm | 2.5kg/box 8boxes/carton |
| 3.2mm | 350mm | 5.0kg/box 4boxes/carton |
| 4.0mm | 400mm | 5.0kg/box 4boxes/carton |
| 5.0mm | 400/450mm | 5.0kg/box 4boxes/carton |
In terms of packaging, paper or plastic boxes are generally used, with a certain number of welding rods inside each box. Common packaging specifications include 5kg/box, 2.5kg/box, etc.
It has a wide range of applications. It is suitable for welding low-carbon steel structures, such as ordinary steel structures, thin plates, pipelines, etc. E6013 welding rod can also play a good role in some occasions with high requirements for weld appearance, such as small mechanical parts, vehicle maintenance, etc. It has stable welding arc, beautiful weld formation, easy slag removal, and good operational performance.
It should be noted that when using E6013 welding electrode for welding, appropriate welding current, voltage and other parameters should be selected according to the specific welding process requirements to ensure welding quality.
