Annealed black iron wire is made from low-carbon steel wire rod as raw material.
The production process usually includes the following main steps:
1. Raw material preparation: Select high-quality low-carbon steel wire rods and inspect and pre treat them.
2. Wire drawing: Use a wire drawing machine to pull the wire rod into the required diameter of iron wire.
3. Annealing treatment: Annealing is carried out in a specific annealing furnace to reduce the hardness of the iron wire and improve its toughness and ductility.
4. Surface treatment: Remove the oxide layer and impurities on the surface to ensure the smoothness of the wire surface.
5. Inspection and packaging: Conduct quality inspection on the finished products and package them after passing the inspection.
Specifications:
WIRE DIAMETER | |||
GAUGE | SWG (mm) | BWG (mm) | AWG (mm) |
6 | 4.877 | 5.16 | 4.11 |
7 | 4.470 | 4.57 | 3.67 |
8 | 4.064 | 4.19 | 3.26 |
9 | 3.658 | 3.76 | 2.91 |
10 | 3.251 | 3.40 | 2.59 |
11 | 2.946 | 3.05 | 2.30 |
12 | 2.642 | 2.77 | 2.05 |
13 | 2.337 | 2.41 | 1.83 |
14 | 2.032 | 2.11 | 1.63 |
15 | 1.829 | 1.83 | 1.45 |
16 | 1.626 | 1.65 | 1.29 |
17 | 1.422 | 1.47 | 1.15 |
18 | 1.219 | 1.24 | 1.02 |
19 | 1.016 | 1.07 | 0.91 |
20 | 0.914 | 0.89 | 0.812 |
21 | 0.813 | 0.81 | 0.723 |
22 | 0.711 | 0.71 | 0.644 |
23 | 0.610 | 0.64 | 0.573 |
24 | 0.559 | 0.56 | 0.511 |
25 | 0.508 | 0.51 | 0.455 |
Applications:
Annealed black iron wire has good flexibility and processability, and is widely used in the following fields:
1. Construction industry: used for making steel mesh, stirrups, etc.
2. Hardware products: such as hangers, hooks, etc.
3. Craft production: Various handmade weaving and decorative crafts.
4. Protection areas: such as fences, protective nets, etc.
5. Binding and fixing: Used in logistics and packaging to bind goods.
Packing:
1. 25kg 50kg per coil inner pack with plastic film then weaving bag or hessian cloth
2.500kg per coil with plastic film then weaving bag
3. 1kg per coil then 10coil or 20coils per bundle
4.1kg per coil then 20kg/carton
Post time: Feb-17-2025
