1.45mm 99.95% pure zinc wire for spraying

Short Description:

  • Origin:China
  • Material:Zinc ingot content ≥ 99.995%
  • Diam:1.30mm
  • Surface:Bright / Smooth
  • Package:25kg 50kg 250kg by coil ,spool ,drum
  • Trade term:FOB, CNF ,CIF
  • Payment term:T/T .L/C
  • MOQ:500KGS
  • Delivery time:10days

Product Detail

Product Tags

High purity 99.995% zinc wire 1.45mm for spraying

Pure Zn is a 99.99% pure zinc wire specifically designed for spraying in arc spray and flame spray systems

99.995% pure zinc wire for spraying manufacturer
High quality purity zinc wire 99.995% 1.2mm 2.0mm manufa
high quality purity zinc wire 99.995% 3.0mm  250kg drum manufacturer

Product Description: The zinc wire has a smooth, bright, fine and consistent appearance, with no broken wires, no oil stains or burrs on a single piece no scratches or scars, moderate softness and hardness, and no jamming during use.

Description Diameter Package  Zinc content Applications
Pure zinc wire Φ1.3mm 25kg/coil;15-20kg/spool;50-200/durm ≥99.9953 Product Description: The zinc wire has a smooth, bright, fine and consistent appearance, with no broken wires, no oil stains or burrs on a single pieceno scratches or scars, moderate softness and hardness, and no jamming during use.
Φ1.6mm ≥99.9953
Φ2.0mm ≥99.9953
Φ2.3mm ≥99.9953
Φ2.8mm ≥99.9953
Φ3.0mm ≥99.9953
Φ3.175mm 250kg/drum ≥99.9953
Φ4.0mm 250kg/drum ≥99.9953



Chemical composition Zn Pb Cd Pb+Cd Sn Fe Cu others
Standard ≥99.99 ≤0.005 ≤0.005 ≤0.006 ≤0.001 ≤0.003 ≤0.002 ≤0.01
Actual value 99.996 0.0014 0.0001 0.0015 0.0003 0.0010 0.0004 0.0032

Physical properties of zinc wire

Items Standard
Tensile strength(Mpa) 115±10
Elongation(%) 52±5
Melting point(°C) 419.5
Density(g/m3) 7.14

The company has XJ-650T extruder and five sets of domestic automated flow casting resistance furnaces, continuous wire pulling production equipment, as well as multiple sets of circulating water tanks, digital precision winding machines, automatic wire dropping machines, packaging machines and other equipment.
Testing:
During the process from raw material (zinc ingot) to stripping, no other components enter and do not come into contact with other metals. Use DF-100 direct reading spectrometer, computerized eddy current testing instrument (eddy current testing series), plasma inductively coupled atomic emission spectroscopy and other detection instruments. Each process from raw materials to cutting, large pulling, medium pulling, water tank, packaging, and storage is checked and inspected layer by layer. Not letting go of small details, so as to ensure the long-term stability of our product performance. Ensure that each batch of zinc wire has a content of over 99.995%, and that the SGS environmental testing results comply with the requirements of the EU RoHS Directive 2002/95/EC and subsequent amendment directives.
Quality:
Strict quality control has formed a production-oriented enterprise with zinc wire as the main product and an annual output of more than 11000 tons of zinc aluminum products. It has established long-term strategic partnerships with multiple state-owned enterprises, central enterprises, listed enterprises, and foreign-funded enterprises, and has exported to East Asia (Japan, South Korea), Southeast Asia, the Middle East, North America, South America, Eastern Europe, Western Europe and other places for a long time. It has established good trade relations with foreign investors and enjoys a good reputation in domestic and foreign markets.
Product features:
1.The size and shape of the spray coating are not affected. It can be sprayed on the overall surface or on large limited surfaces, which is a convenient and economical method for coating local surfaces of large components.
2. The parent material remains unchanged. Due to the low heating temperature of the base material during spraying construction, the deformation of the workpiece is small.
3. The coating thickness can vary widely, and the thickness formed by spraying can range from a few micrometers to several millimeters.
4. It can be spray formed. Thermal spraying technology can not only form coatings on the surface of materials, but also be used to manufacture mechanical parts, namely spray formed products.
The anti-corrosion performance of hot-dip zinc spray can ensure the durability of components for more than 20-40 years when the spray thickness is only 0.08-0.4mm in different atmospheric environments and water quality. It is currently the ideal material for anti-corrosion.
Transportation and storage:
It is prohibited to use packaging materials and transportation vehicles that corrode zinc with acid, alkali, salt, etc. for transportation, and they should be stored in a dry, ventilated, and non corrosive warehouse to prevent rainwater from getting wet.

Pure Zinc Wire Applications:

Pure zinc wire has a wide range of applications in various fields. The following are the main application areas and specific uses of pure zinc wire:
1. Electrical industry: Pure zinc wire can be used to manufacture wires, cables, and electrical equipment, utilizing its excellent conductivity.
2. Anti corrosion coating: Pure zinc wire can be used to manufacture anti-corrosion coatings, such as hot-dip galvanized wire, which can form a protective film on the surface of metal products, prevent metal oxidation and corrosion, and extend service life.
3. Metal processing: Pure zinc wire can be used to manufacture various metal products, such as iron crafts, metal mesh, etc. Its corrosion resistance and ease of processing make it an ideal material for the metal processing industry.
4. Electroplating process: Pure zinc wire can be used in electroplating process to cover the metal surface with zinc, increasing surface hardness and corrosion resistance
